Cut Tube
Pneumatic rotary blade pipe cutter.
Taglia tubi a lame rotanti pneumatica.
SPECIFICATIONS:
Name: Cut Tube
Model: 800.5
Electrical: 230V - 0.75Kw.
System Control: INVERTER.
Air pressure: 8 bar
Materials: iron, stainless, galvanized, copper.
Thickness: 0.4 - 0.6 mm.
Diameter range: Ø 80 - 800 mm.
Time Cycle: max 30 sec.
Pieces per hour: 10 - 150 pz/h.
Dimensions LxWxH: 1150x500x1500 mm.
Weight: 250Kg.
Cut Tube
Pneumatic rotary blade pipe cutter.
Taglia tubi a lame rotanti pneumatica.
SPECIFICATIONS:
Name: Cut Tube
Model: 800.5
Electrical: 230V - 0.75Kw.
System Control: INVERTER.
Air pressure: 8 bar
Materials: iron, stainless, galvanized, copper.
Thickness: 0.4 - 0.6 mm.
Diameter range: Ø 80 - 800 mm.
Time Cycle: max 30 sec.
Pieces per hour: 10 - 150 pz/h.
Dimensions LxWxH: 1150x500x1500 mm.
Weight: 250Kg.
